Cheat Sheet: Agents and Orchestration

Fast revision for choosing between model-decided and deterministic control flow, and the Bedrock services that back each one.

Options at a glance

The split on the agent rows is who writes the loop. The harness takes a declaration and runs the cycle for you; the runtime takes an agent you wrote on any framework and runs the operational pieces around it. The harness sits on the runtime’s per-session microVMs, and both draw on the same memory, gateway, identity, and observability.

Decision rules

• If there is no loop and no external data, use a plain Converse call.
• If the model needs to fetch data or take an action, use tool use in the Converse loop.
• If you want validated JSON out, send a JSON schema in outputConfig.textFormat, or mark the tool definition strict: true.
• If the order of steps comes out of the model at runtime rather than out of your code, that is model-decided control flow, so reach for an agent: the harness when a declared model, prompt, and tool list covers it, your own loop on the runtime when it does not.
• If the sequence is fixed and you own it, that is deterministic control flow, so use Flows or Step Functions.
• If the pipeline is low-code, Bedrock-native, and built from prompts, conditions, and knowledge base lookups, use Bedrock Flows.
• If you need durable state, retries, timeouts, parallel branches, or a pause for human approval, use Step Functions.
• If the agent needs grounding from your own content, attach a knowledge base rather than stuffing documents into the prompt.
• If work splits into distinct specialisms, expose each specialist agent as a tool and let a coordinating agent call them.
• If a Lambda or REST API backs the tool, attach it to the gateway as a target; a remote MCP server attaches to the harness by URL with no gateway, and an inline function tool returns the call to your own code.
• If you are debugging why an agent did something, turn on CloudWatch Transaction Search for the account, enable tracing on the resource, and instrument your agent code with ADOT. Built-in metrics arrive without any of that.
• If you run a third-party framework agent in production, host it on the AgentCore runtime for memory, gateway, and identity.
• If a tool must never exceed a permission, put that limit in IAM or a gateway policy, not the prompt.

Traps

• An agent is not always the answer; a fixed workflow is cheaper, faster, and more predictable as Flows or Step Functions.
• Your code runs the tool in the Converse loop. The model emits a tool-use request with stopReason of tool_use, and you return a toolResult. Bedrock executes tools itself only in server-side tool use on the Responses API, which calls a Lambda or an AgentCore Gateway.
• Every toolResult must echo the toolUseId from the request, or the turn will not stitch together.
• Structured output is its own feature, not a tool-schema workaround: outputConfig.textFormat on Converse, strict: true on a tool definition, or both together. An unsupported schema comes back as a 400 before any inference runs.
• An inline function tool does not mean no Lambda ever; it means the harness pauses and returns the call to your application instead of the gateway invoking the target itself.
• A Lambda gateway target runs under the gateway’s own permissions, so it cannot act as the signed-in user. Three-legged OAuth on an MCP or OpenAPI target does that, or an inline function tool in your own code.
• Tool permissions live in IAM, and in the Cedar policies a gateway evaluates before each call. A prompt saying please do not delete is not a control.
• Agent memory is not the context window. Short-term is the session; long-term persists across sessions and needs a memory strategy attached.
• Flows has condition, loop, knowledge base, Lambda and inline code nodes, and no retry, wait, or approval node. Those are Step Functions.
• Step Functions calls AgentCore through an InvokeHarness task, request-response only: no .sync, no task-token callback, and the task state stops at 15 minutes.
• AgentCore is a framework-agnostic platform, not a model. You bring the agent, or declare one on the harness.
• Knowledge base grounding is retrieval, not fine-tuning. It changes what the agent can look up, not the model weights.
• Bedrock Agents is now Bedrock Agents Classic, closed since 30 July 2026 to accounts with no prior use, so its supervisor-and-collaborator routing is not a live option. The harness does agent-as-tool; richer routing means framework code on the runtime.

Say it in one line

1. Model-decided control flow means an agent; deterministic control flow means Flows or Step Functions.
2. Tool use: the model requests, your code executes, you send the toolResult back keyed by toolUseId.
3. Structured output is a schema Bedrock enforces, through outputConfig.textFormat or a strict tool definition.
4. The harness orchestrates the loop from a declaration; the runtime runs a loop you wrote yourself. Same capabilities underneath, different owner of the cycle.
5. A gateway target publishes an existing Lambda or REST API to the agent as an MCP tool; an inline function tool returns the call to your app instead.
6. Memory strategies decide what long-term memory gets extracted; a memory resource with none attached keeps the session and stores nothing across sessions.
7. Metrics arrive by default; spans need Transaction Search, tracing switched on, and ADOT in your agent code.
8. Multi-agent on the harness is agent-as-tool: expose a specialist agent through the gateway and let another agent call it.
9. Step Functions is durable orchestration: retries, parallel, timeouts, human-approval waits, broad integration, the model as one step.
10. Least privilege lives on the tool’s IAM role and the gateway’s policies, never in the prompt.
11. Pick the least powerful option that fits: plain call, then tool loop, then agent, and orchestrate the rest deterministically.
